Technologies

• Andros™ Stem

  Adjust to fit

  The Andros is our patented adjustable stem that lets you set your handlebars where you want—no tools, no fuss. In just seconds, you can set your riding position to long and low in a tough headwind, or upright and comfy for riding around town. You decide how you want to ride and the Andros makes your bike fit.



  Close
• Bosch PowerPack Battery

  Feather-light powerhouse

  This impressive high-energy, high-power cell carries 300 watt-hours (Wh) of power in the EU, and 400 Wh in the U.S. The best-in-class design charges fast—from zero—in only 2.5 to 3.5 hours, and lets you ride longer and further between charges. You’ll be impressed by its long lifespan, light weight, and ease of charging.



  Close
• Bosch Purion Control Panel

  Compact control center

  The on-board computer lets you switch between five different riding modes, and feeds you handy information like speed, battery level, and distance. It optimizes shifting actions and constantly updates you on the remaining range, just like a typical German car. Best of all, it’s now more compact and robust than ever.



  Close
• OCL™ Frame Joint

  Advanced folding technology

  The key to any folding bicycle is the main folding joint. Done well, it locks the two halves of the frame together without any hint of movement or sound. It should be easy to operate and work flawlessly year after year. The OCL Joint does all of these things and is a new reference in folding frame technology.



  Close

Technical description

• FRAME

  Alu 6061
• Fork

  Tern Tarsus, 6061-Al, hydroformed
• Engine

  Bosch Gen.3 Performance, 300% Assist, 65 Nm Torque, max speed 25 kph
• Battery

  Bosch PowerPack 500 Wh
• Rear derailleur (rear shifter)

  Shimano Deore Shadow+
• Gear change

  Shimano Deore, 1 x 10 spd
• front brake

  Magura MT4, hydraulic disc
• Rear brake

  Magura MT4, hydraulic disc
• Brake levers

  Magura, hydraulic disc
• Crank

  Vektron custom, forged 6061-AL crankarm
• Bottom bracket

  Motor integrated
• Headset

  Tern "Flux Pro"
• Pedals

  MKS EZY
• Cartridge

  Shimano 11-36T, 10 spd
• Chain

  10 spd, DHT for eBike, GST corrosion resistant coating
• Number of speeds

  1 x 10
• Handlebars

  Tern Physis 3D, 3D forged, 5 patented technologies, Kinetix Comp, double-butted 6061-AL, Tern Andros adapted
• Seatpost

  Tern Telescope, 34.9/30.9 mm, 2014-AL, clamp Tern Collar, 6061-AL, 2pc
• Saddle

  Tern Porter+, patented GripPad design, PrimeGel padding
• Grips

  Ergon
• Front hub

  Novatec, sealed cartridge bearing, disc
• Rear hub

  Novatec, sealed cartridge bearing, disc
• Rims

  Kinetix Comp, for disc
• Tires

  Schwalbe Big Apple, Performance Line, 55-406, puncture protection, Reflex
• WEIGHT

  22.1 kg
• Dimensions when folded

  41 × 86 × 68 cm
• Recommended height of rider

  147 - 195 cm
• Load capacity

  max. 125 kg
• Max. weight of rider

  105 kg
• Display

  Bosch Purion, 4 mode selectable, walk assist
• Charger

  220V, 4A
• BELL

  Aluminum
• STAND

  URSUS, rear mount
• Coupling mechanism

  Magnetix 3.0
• Front light

  Tern Valo Direct, 190 lumens
• Tail light

  Herrmans H-Trace, for eBike
• Mudguards

  SKS, stainless hardware
• carrier

  Atlas V Rack™, integrated 8 point mounting; Max load weight: 27 kg

Other

• Product code

  N22000007
