Technologies

• Disc Brakes

  Guaranteed powerful braking power even in the most demanding conditions,it will last much longer than traditional brakes.



  Close
• Inner Cable Routing

  Wiring inside the tubes increases durability of the cables protecting them from mud, sand and rain. It also helps save precious grams and achieve professional sports-round character.



  Close
• Powder Coated

  The coating technology using molecules on aluminum powder electrified using heat. Result is perfectly smooth material, highly resistant to mechanical damage.



  Close
• RHS System

  We created a system of exchangeable dropouts in order to protect our frames as much as possible. In case of damage they can be easily and quickly exchanged. Screws or a special nut are used for the dropout in order to minimize frame damage.



  Close
• T-Head Tube

  Tapered head frame with gradually changing diameters from 1 1/8" at the top and 1.5" at the bottom. The larger diameter at the bottom provides increased durability as well as stiffness resulting in greater steering precision.



  Close
• Thru-Axle 12X142

  Wheel hub in the 142 x 12 mm standard means wheel rigidity comparable with downhill specific bikes but with easy dismounting system. Wider hub allows to stiff the whole construction of wheel and rear triangle which adds precision and stability during riding.



  Close

Technical description

• Frame

  ALUMINIUM PERFORMANCE
• Fork

  CARBON
• Rear derailleur (rear shifter)

  MICROSHIFT SWORD G7005M
• Gear change

  MICROSHIFT SWORD G7000
• front brake

  TEKTRO C550, disc TEKTRO TR160 160 CL
• Rear brake

  TEKTRO C550, disc TEKTRO TR160 160 CL
• Brake levers

  MICROSHIFT SWORD SB-G7000
• Crank

  PROWHEEL
• Bottom bracket

  PROWHEEL BB68+
• Headset

  FSA 1-1/8"/1.5"
• Cartridge

  MICROSHIFT H104 11-48T
• Chain

  SHIMANO HG54
• Number of speeds

  10
• Handlebars

  ALUMINIUM 31.8 (XS - 380 MM; S - 400 MM; M, L - 420 MM; XL - 440 MM)
• Stem

  ALUMINIUM 31,8/7° (XS, S - 60 MM: M, L - 70 MM; XL - 80 MM)
• Seatpost

  ALUMINIUM 27,2 (XS, S, M, L - 350 MM; XL - 400 MM)
• Saddle

  SELLE ROYAL COMFORT GROOVE
• Grips

  FIZIK
• Front hub

  SHIMANO RS470 12x100
• Rear hub

  SHIMANO GRX RS470
• Rims

  ALUMINIUM
• Tires

  WTB RESOLUTE COMP 700x42C
• Weight

  11,55 kg

Other

• Product code

  N25000001
